For loaded working side:
The axial force fax1d of hypoid gear pinion is:
The axial force fax2d of hypoid gear wheel is:
For non working side without load:
The axial force fax1c of hypoid gear pinion is:
The axial force fax2c of the large axle of hypoid gear is:
Where, α NC – normal pressure angle of non working tooth surface of gear cutting; α Nd – normal pressure angle of tooth surface of hypoid gear for gear cutting. Subscript “2” indicates the parameters of large hypoid gear and subscript “1” indicates the parameters of small hypoid gear.
